ANSI A137.3—2017, A108.19—2020 and A108.20—2021
American National Standard Specifications
for Gauged Porcelain Tile and Gauged Porcelain Tile Panels/Slabs
(Material and Installation Standards)
Release date: January 2021

American National Standard Specification A137.3 describes the minimum physical properties and grading procedures for gauged porcelain tiles and gauged porcelain tile panels/slabs. It provides quality criteria for buyers, specifiers, installers, manufacturers, and the public in general. ”Gauged” means manufactured to a thickness that is specific and largely associated with installation and use. Tile panels/slabs are those that are one square meter in facial area or larger. Some of the key issues addressed by this standard are:

• Floor, wall, and countertop strength criteria for “Table 4” gauged products that have a declared nominal thickness within the range of 5.0 to 6.5 mm
• Wall and countertop strength criteria for “Table 5” gauged products that have a declared nominal thickness within the range of 3.5 to 4.9 mm
• Thickness accuracy and precision criteria
• Provisions for sampling and visual inspection, considering tile panels/slabs can be very large
• Provisions for gauged products with back layer reinforcing

American National Standard A108.19 provides procedures and requirements for interior installation of gauged porcelain tiles and gauged porcelain tile panels/slabs. These products require unique installation and workmanship considerations, and some of the key issues addressed by this standard addresses include:

• Floor and wall installation procedures for ANSI A137.3 “Table 4” gauged products
• Wall installation procedures for ANSI A137.3 “Table 5” gauged products
• Substrate requirements
• Lippage criteria and use of lippage control systems
• Unique coverage criteria and evaluation procedures
• Special floor setting provisions that involve embedding by walking

American National Standard A108.20 provides procedures and requirements for exterior installation of gauged porcelain tiles and gauged porcelain tile panels/slabs.  These products require unique installation and workmanship considerations, and some of the key issues addressed by this standard addresses include:

• Exterior vertical and overhead installation procedures for ANSI A137.3 gauged products
• Substrate requirements
• Lippage criteria and use of lippage control systems
• Unique coverage criteria and evaluation procedures
• Specific embedding instructions

Please note: Hard copy orders of this title will be filled with the A137.3 and A108.19 (April 2020 release) with an errata sheet inserted to include A108.20 (added January 2021). Digital copies will have A108.20 integrated.
